RoHS and REACH Declarations for Silane Coupling Agents

2026-10-25

Sourcing engineers need to verify that silane coupling agents meet RoHS and REACH regulations, confirm technical specifications, and understand trade terms before placing orders. This guide details the regulatory compliance status of standard aminopropyl and epoxy silanes, provides verifiable specification parameters such as purity and CAS numbers, and outlines standard packaging sizes and international trade terms for export shipments.

Table of Contents

1. Regulatory Scope for Silane Coupling Agents

RoHS (Restriction of Hazardous Substances) primarily applies to electrical and electronic equipment, limiting specific heavy metals and phthalates. REACH applies to chemicals manufactured or imported into the European Economic Area, focusing on the registration, evaluation, and restriction of chemicals, particularly Substances of Very High Concern (SVHC). For liquid silanes supplied in drums, RoHS concentration limits apply to the substance as a homogeneous material.

1. Regulatory Scope for Silane Coupling Agents

2. RoHS Restricted Substances in Silane Synthesis

The RoHS 3 directive restricts lead, mercury, cadmium, hexavalent chromium, PBBs, PBDEs, and four specific phthalates (DEHP, BBP, DBP, DIBP). Silane synthesis rarely utilizes these substances intentionally. However, trace heavy metals may appear as impurities if specific metal-based catalysts are employed during the hydrosilylation reaction.

SubstanceRoHS Limit (w/w)Typical Silane Impurity LevelValidity Condition
Lead0.1%< 10 ppmWhen no lead-based catalysts are used
Cadmium0.01%< 2 ppmUnder standard fractional distillation processes
DEHP0.1%Not detectedWhen plastic-free packaging and piping are used

3. REACH SVHC and Registration Requirements

REACH requires registration for substances imported in quantities of 1 tonne or more per year. The SVHC candidate list is updated biannually. Some silanes hydrolyze into silanols upon exposure to moisture, and specific hydrolysis products may be classified as SVHCs.

A silane coupling agent is considered REACH compliant for a specific application only if its hydrolysis products and the parent compound both remain below the 0.1% w/w SVHC threshold under standard storage conditions (20°C, <50% humidity).

4. Technical Specification and Compliance Parameters

To verify specification compliance, sourcing engineers must review the Certificate of Analysis (COA) against the declared parameters. The following table outlines the standard verifiable parameters for a primary grade, KH-550. When reviewing a COA, verify that the purity is determined by Gas Chromatography and that the moisture content is measured via Karl Fischer titration. A purity of 98% indicates that the remaining 2% may contain moisture or low-boiling alcohols. For export shipments, controlling moisture is critical because water ingress during transit can initiate self-condensation, reducing the effective silane content and increasing viscosity.

ParameterSpecification for KH-550Test Method / Condition
Chemical Namegamma-aminopropyltriethoxysilane-
CAS Number919-30-2-
Molecular FormulaC9H23NO3Si-
Purity (GC)≥ 98.0%Gas Chromatography
Moisture (Karl Fischer)≤ 0.2%Coulometric Titration
Net Weight200 kg / drumSteel drum with nitrogen padding

Verification protocols for restricted substances require Inductively Coupled Plasma Mass Spectrometry (ICP-MS) for heavy metals and Gas Chromatography-Mass Spectrometry (GC-MS) for phthalates. For technical validity, ICP-MS detection limits must be at least 10 times lower than the RoHS threshold to account for analytical uncertainty.

5. Packaging, Pallet Loading and Trade Terms

Standard export packaging for liquid silane coupling agents is 200 kg net weight per steel drum, sealed with a nitrogen pad to prevent moisture ingress. For bulk orders, IBC tanks (1000 kg) or ISO tanks are available upon request. Drums must be stored in a cool, dry, and well-ventilated area, away from direct sunlight to ensure chemical stability.

When calculating logistics, the standard pallet loading quantity for 200 kg drums is 4 drums per pallet, arranged in a 2x2 configuration and secured with stretch film. A standard 20-foot freight container can accommodate 16 pallets, yielding a total loading capacity of 64 drums (12.8 metric tonnes) per container. A 40-foot container holds 32 pallets, totaling 128 drums (25.6 metric tonnes).

For international trade, standard Incoterms apply. Ex-works (EXW) is used when the buyer arranges all freight from the origin facility. Free on Board (FOB) is the most common term for sea freight, where the seller covers transport and export customs clearance to the named port of loading. Cost, Insurance and Freight (CIF) is utilized when the seller assumes the cost of freight and marine insurance to the destination port. All trade terms and final freight costs are subject to confirmation at the time of order.

6. Common Silane Grades and Public Constants

Standard commercial grades of silane coupling agents are formulated to meet international regulatory requirements. The table below outlines the public constants and recommended starting dosage ranges for common grades. The extent of dosage optimization must be confirmed in your own trial, as it depends on the specific filler surface area and resin system.

GradeCAS NumberChemical NameFunctional GroupRecommended Dosage Range
KH-550919-30-2gamma-aminopropyltriethoxysilaneamino (basic)0.5%-1.5% of filler weight; 0.3%-1% in aqueous systems
KH-5602530-83-8gamma-glycidoxypropyltrimethoxysilaneepoxy (neutral)0.5%-1.5% of filler weight
KH-5702530-85-0gamma-methacryloxypropyltrimethoxysilanemethacryl0.5%-1.5% of filler weight

FAQ

Can you provide samples and test data for evaluation?

We can supply 100 g laboratory samples. A Certificate of Analysis (COA) is provided with the shipment. Please confirm specific specifications and testing items with our sales team.

During production, should I add the silane coupling agent before or after the resin and filler?

The silane must be hydrolyzed to form silanols before adding the filler or resin. Direct mixing causes uneven dispersion and self-condensation. Hydrolysis is complete when the solution becomes clear; prepare the solution immediately before use and do not store it.

Why can I not simply reuse the previous dosage amount when switching to a new batch of filler?

The specific surface area, surface hydroxyl density, and moisture content of the filler may vary between different batches or systems. These variations change the optimal dosage, so small-scale trials must be conducted to re-verify the exact amount required.

How long can I store silane coupling agent after the drum has been opened?

Storage duration must follow the packaging label. Once opened, the product easily absorbs moisture and hydrolyzes. It is recommended to seal the drum tightly, store it in a cool, dry, and dark place, and use it as soon as possible.

Is the silane dosage calculated based on the weight of the filler or the weight of the resin?

The dosage must be calculated based on the mass of the inorganic filler or glass fiber. The function of the silane is to form a monomolecular layer on the inorganic surface, which is independent of the total resin amount. Deduct the moisture and volatiles from the filler weight when calculating.
