When selecting between KH-560 and KH-570 for mineral-filled resins, the correct choice depends on the matrix cure mechanism. KH-560 contains an epoxy group for amine-cured epoxies, while KH-570 contains a methacrylate group for free-radical acrylics. Matching the organofunctional group to the resin prevents phase separation and ensures chemical bonding at the filler-matrix interface under thermal stress.
Table of Contents
- 1. Chemical Structure and Reactivity Differences
- 2. Hydrolysis and Condensation Parameters
- 3. Application in Epoxy and Acrylic Matrices
- 4. Thermal Stability Limits
- 5. Formulation and Dosage Guidelines
- 6. Specification Compliance and Purity Parameters
- 7. Packaging and Trade Conditions
1. Chemical Structure and Reactivity Differences
KH-560 (gamma-glycidoxypropyltrimethoxysilane) features an epoxy ring that reacts with amines, acids, or anhydrides. KH-570 (gamma-methacryloxypropyltrimethoxysilane) features a methacryloxy group that reacts via free-radical initiation. Both share a trimethoxysilyl tail that bonds to inorganic substrates.
| Grade | Chemical Name | CAS Number | Functional Group | Boiling Point (at 10 mmHg) | Recommended Dosage Range |
|---|---|---|---|---|---|
| KH-560 | gamma-glycidoxypropyltrimethoxysilane | 2530-83-8 | Epoxy (Glycidoxy) | 152 °C | 0.5%-1.5% of filler weight |
| KH-570 | gamma-methacryloxypropyltrimethoxysilane | 2530-85-0 | Methacrylate | 108-110 °C | 0.5%-1.5% of filler weight |
2. Hydrolysis and Condensation Parameters
Both require hydrolysis of the methoxy groups to form silanols before condensing with inorganic substrates. For non-amino silanes like KH-560 and KH-570, hydrolysis is optimized at pH 4.0 to 5.0 in water-alcohol mixtures. KH-570 hydrolyzes faster due to lower steric hindrance but is more prone to self-condensation if the pH exceeds 6.0. Aqueous solutions must be prepared immediately before use and not stored, as they will gel.
3. Application in Epoxy and Acrylic Matrices
In epoxy systems, KH-560 participates directly in the crosslinking network. When used at the recommended dosage relative to silica filler, lap shear strength of aluminum-epoxy joints increases after humidity aging. KH-570 does not react with amine hardeners and acts only as a physical barrier, leading to interfacial failure under moisture exposure. Conversely, in UV-curable acrylic adhesives, KH-570 copolymerizes with the acrylate matrix, while KH-560 remains unreacted and plasticizes the interface.
4. Thermal Stability Limits
The thermal stability of the siloxane bond is similar for both grades, but the organic functional groups degrade at different temperatures. The epoxy ring in KH-560 begins to undergo thermal ring-opening above 200 °C in the presence of residual amines. The methacrylate double bond in KH-570 is stable up to 220 °C under inert nitrogen, but degrades rapidly above 180 °C in air due to radical oxidation. For continuous service temperatures exceeding 180 °C in oxidative environments, KH-560 provides more reliable interfacial retention when properly cured.
5. Formulation and Dosage Guidelines
Dosage must be calculated based on the specific surface area of the inorganic filler. For standard precipitated silica, a monolayer coverage requires 0.5%-1.5% of either silane relative to the filler weight. Exceeding this range leads to multilayer formation, which reduces cohesive strength. The exact dosage extent must be confirmed in your own trial, as it depends on the specific filler characteristics and process fluctuations.
6. Specification Compliance and Purity Parameters
When evaluating a silane coupling agent for your specification, verifiable parameters must be reviewed against the Certificate of Analysis (COA). Buyers and sourcing engineers should request the gas chromatography purity report and verify that the main peak area ratio and free acid value fall within the specified limits. The exact limit values are defined by the contract specification sheet.
| Grade | Chemical Name | CAS Number | Functional Group | Density (25 °C) | Boiling Point (10 mmHg) | Purity (GC) | Net Weight |
|---|---|---|---|---|---|---|---|
| KH-560 | gamma-glycidoxypropyltrimethoxysilane | 2530-83-8 | Epoxy | 1.075 g/cm³ | 152 °C | ≥ 98.0% | 25 kg |
| KH-570 | gamma-methacryloxypropyltrimethoxysilane | 2530-85-0 | Methacryl | 1.045 g/cm³ | 109 °C | ≥ 98.0% | 25 kg |
The molecular formula defines the reactive groups. KH-560 (C9H20O5Si) has one epoxy ring and three methoxy groups. KH-570 (C10H20O5Si) has one methacrylate bond and three methoxy groups. Purity is determined via gas chromatography. Net weight is standardized at 25 kg per drum for accurate batching. Density and boiling point are physical constants providing quick verification for receiving inspectors.
7. Packaging and Trade Conditions
Proper packaging is critical to prevent moisture ingress, which can trigger premature hydrolysis and self-condensation of the silane. Both KH-560 and KH-570 are supplied in 25 kg high-density polyethylene (HDPE) drums or 200 kg steel drums, depending on the order volume. The drums must be kept tightly sealed in a dry, well-ventilated area away from direct sunlight.
For international shipping, standard pallet loading configurations are used to optimize container space. A 20-foot container typically holds 20 pallets, accommodating up to 20 metric tons (800 drums of 25 kg), while a 40-foot container holds up to 40 metric tons. Pallets are shrink-wrapped and secured with straps to prevent movement during ocean freight.
Standard trade terms follow Incoterms 2020. We commonly quote FOB (Free On Board) for ports in China, where the buyer assumes risk once the goods are loaded on the vessel. CIF (Cost, Insurance, and Freight) is also available to named destination ports, where the seller covers freight and minimum insurance coverage. The specific Incoterm and delivery schedule are subject to confirmation at the time of order.
Containers must be inspected for leaks before dispatch. Transit temperatures should not exceed 40 °C. Upon arrival, verify drum seals and net weight against the packing list. Document any discrepancies immediately. For custom packaging like IBCs, arrange in advance. The choice between FOB and CIF depends on your logistics capabilities. Consult local customs brokers for the correct HS code to ensure smooth import clearance. Laboratory samples are supplied as 100 g bottles only, which is sufficient for initial small trials. COA and MSDS are supplied with every shipment.
FAQ
How do I verify the purity of a long-chain silane before bulk purchase?
Request a gas chromatography purity report and COA from the supplier. Verify that the main peak area ratio and free acid value fall within the specification limits. The exact limit values are determined by the contract specification sheet.
We added silane but pull-off adhesion is still below spec. What should we check first?
Check three aspects: whether the hydrolyzed solution is clear (for non-amino silanes, pH must be 4-5), if the dosage is within the reasonable range, and whether substrate cleanliness and curing conditions meet the requirements.
The hydrolyzed silane solution turned cloudy with sediment the next day. Can we still use it on the filler?
No. Cloudiness indicates the silane has undergone self-condensation and lost coupling activity. You must prepare a fresh solution. Adjust non-amino silane pH to 4-5, do not adjust pH for aminosilanes, and prepare immediately before use.
Why should production dosage be set at 92%–95% of the peak value instead of the exact peak?
The peak region is highly sensitive to dosage fluctuations and has a narrow error tolerance. Using a dosage slightly below the peak is more stable for actual production. The exact value must be determined through small-scale trials and scale-up validation.
The same formulation failed to bond after switching to a new silane batch. What causes this?
This is often caused by moisture or purity fluctuations in the new silane batch, or changes in filler moisture content, leading to differences in hydrolysis and interfacial reactions. Review the batch COA and filler drying process, and verify with a small trial.
Is pre-treating the filler surface more cost-effective than adding silane directly to the bulk resin?
Pre-treating the filler surface usually provides more uniform coating and more stable interfacial bonding. Adding it to the bulk requires the silane to migrate through the resin melt to the interface, which is less efficient. Selection depends on equipment, batch size, and cost.
